Building A Real-Time Morse Code Translator With Python For IoT Applications

Morse code may seem like an old method of communication, but it still suits modern applications where simple, signal-based messaging is required. In this project, we use Python to build a Morse code translator that can convert between English text and Morse code. What makes it interesting is how we connect it with IoT devices to send and receive messages in real time. With a few lines of code and basic hardware, we turn Morse signals into readable messages and back, making the morse code translator useful for low-power or remote communication setups.

Table of Contents

Morse Code: An Overview

Morse code is a method of communication that uses a sequence of dots and dashes to represent letters, numbers, and symbols. It was created in the 1830s by Samuel Morse and Alfred Vail for use with the telegraph, a device that sent electrical signals over wires.

This system can transmit messages through sound, light, or electrical pulses. While no longer widely used, Morse code still plays a role in fields like aviation and amateur radio, where reliable signal-based communication is essential.

How It Works

In Morse code, each letter, number, and symbol is represented by a unique combination of dots (short signals) and dashes (long signals). For instance, the letter “A” is written as a dot followed by a dash (·−), while “B” is a dash followed by three dots (−···).

The timing of signals is standardized. A dot lasts for one unit of time, a dash lasts for three units, spaces between parts of the same letter last for one unit, spaces between letters last for three units, and spaces between words last for seven units. This consistency helps in sending and receiving messages clearly and accurately.

Implementation in Python

To create a Morse code translator, we will implement:

A mapping of characters to Morse code
A function to encode a message into Morse code
A function to decode Morse code back into a message

Mapping Characters to Morse Code

We create a dictionary that links letters, numbers, and symbols to their Morse code patterns.

morse_dict = {
‘A’: ‘.-‘, ‘B’: ‘-…’, ‘C’: ‘-.-.’, ‘D’: ‘-..’, ‘E’: ‘.’, ‘F’: ‘..-.’, ‘G’: ‘–.’, ‘H’: ‘….’,
‘I’: ‘..’, ‘J’: ‘.—‘, ‘K’: ‘-.-‘, ‘L’: ‘.-..’, ‘M’: ‘–‘, ‘N’: ‘-.’, ‘O’: ‘—‘, ‘P’: ‘.–.’,
‘Q’: ‘–.-‘, ‘R’: ‘.-.’, ‘S’: ‘…’, ‘T’: ‘-‘, ‘U’: ‘..-‘, ‘V’: ‘…-‘, ‘W’: ‘.–‘, ‘X’: ‘-..-‘,
‘Y’: ‘-.–‘, ‘Z’: ‘–..’, ‘0’: ‘—–‘, ‘1’: ‘.—-‘, ‘2’: ‘..—‘, ‘3’: ‘…–‘, ‘4’: ‘….-‘,
‘5’: ‘…..’, ‘6’: ‘-….’, ‘7’: ‘–…’, ‘8’: ‘—..’, ‘9’: ‘—-.’, ‘.’: ‘.-.-.-‘, ‘,’: ‘–..–‘,
‘?’: ‘..–..’, “‘”: ‘.—-.’, ‘!’: ‘-.-.–‘, ‘/’: ‘-..-.’, ‘(‘: ‘-.–.’, ‘)’: ‘-.–.-‘, ‘&’: ‘.-…’,
‘:’: ‘—…’, ‘;’: ‘-.-.-.’, ‘=’: ‘-…-‘, ‘+’: ‘.-.-.’, ‘-‘: ‘-….-‘, ‘_’: ‘..–.-‘, ‘”‘: ‘.-..-.’,
‘$’: ‘…-..-‘, ‘@’: ‘.–.-.’, ‘ ‘: ‘/’
}

In this dictionary:

The dots and dashes form the code for letters, numbers, and symbols.
The slash (/) marks the space between words.

Encoding a Message to Morse Code

Encoding a message into Morse code means converting each letter or symbol into a series of dots and dashes. This process turns normal text into a special format used historically for communication.

For example, the message Hello World will become

…. . .-.. .-.. — / .– — .-. .-.. -..

Note: There is a space after each Morse code for a character and a slash (/) between words.

Here is the function to encode a message to Morse code:

# Morse code dictionary for encoding
morse_dict = {
‘A’: ‘.-‘, ‘B’: ‘-…’, ‘C’: ‘-.-.’, ‘D’: ‘-..’, ‘E’: ‘.’,
‘F’: ‘..-.’, ‘G’: ‘–.’, ‘H’: ‘….’, ‘I’: ‘..’, ‘J’: ‘.—‘,
‘K’: ‘-.-‘, ‘L’: ‘.-..’, ‘M’: ‘–‘, ‘N’: ‘-.’, ‘O’: ‘—‘,
‘P’: ‘.–.’, ‘Q’: ‘–.-‘, ‘R’: ‘.-.’, ‘S’: ‘…’, ‘T’: ‘-‘,
‘U’: ‘..-‘, ‘V’: ‘…-‘, ‘W’: ‘.–‘, ‘X’: ‘-..-‘, ‘Y’: ‘-.–‘,
‘Z’: ‘–..’, ‘0’: ‘—–‘, ‘1’: ‘.—-‘, ‘2’: ‘..—‘, ‘3’: ‘…–‘,
‘4’: ‘….-‘, ‘5’: ‘…..’, ‘6’: ‘-….’, ‘7’: ‘–…’, ‘8’: ‘—..’,
‘9’: ‘—-.’, ‘.’: ‘.-.-.-‘, ‘,’: ‘–..–‘, ‘?’: ‘..–..’, “‘”: ‘.—-.’,
‘!’: ‘-.-.–‘, ‘/’: ‘-..-.’, ‘(‘: ‘-.–.’, ‘)’: ‘-.–.-‘, ‘&’: ‘.-…’,
‘:’: ‘—…’, ‘;’: ‘-.-.-.’, ‘=’: ‘-…-‘, ‘+’: ‘.-.-.’, ‘-‘: ‘-….-‘,
‘_’: ‘..–.-‘, ‘”‘: ‘.-..-.’, ‘$’: ‘…-..-‘, ‘@’: ‘.–.-.’, ‘ ‘: ‘/’
}

def to_morse_code(message):
message = message.upper()
morse_code = ”
for char in message:
if char in morse_dict:
morse_code += morse_dict[char] + ‘ ‘
else:
morse_code += ”
return morse_code.strip()

# Example usage:
message = “Hello World”
print(to_morse_code(message))

The function to_morse_code works like this:

It converts the input message to uppercase because Morse code does not differ by case.
It looks up each character in the dictionary and adds the corresponding Morse code followed by a space.
It returns the full Morse code sequence with spaces between codes and slashes for spaces.

Decoding a Message from Morse Code

We create a function that takes a Morse code string made of dots, dashes, spaces, and slashes. It returns the normal message for that code.

For example, the Morse code

.. / .- — / .- / … — ..-. – .– .- .-. . / -.. . …- . .-.. — .–.

will become

I AM A SOFTWARE DEVELOPER

Here is the function to decode a message from Morse code:

# Morse code dictionary
morse_dict = {
‘A’: ‘.-‘, ‘B’: ‘-…’, ‘C’: ‘-.-.’, ‘D’: ‘-..’, ‘E’: ‘.’,
‘F’: ‘..-.’, ‘G’: ‘–.’, ‘H’: ‘….’, ‘I’: ‘..’, ‘J’: ‘.—‘,
‘K’: ‘-.-‘, ‘L’: ‘.-..’, ‘M’: ‘–‘, ‘N’: ‘-.’, ‘O’: ‘—‘,
‘P’: ‘.–.’, ‘Q’: ‘–.-‘, ‘R’: ‘.-.’, ‘S’: ‘…’, ‘T’: ‘-‘,
‘U’: ‘..-‘, ‘V’: ‘…-‘, ‘W’: ‘.–‘, ‘X’: ‘-..-‘, ‘Y’: ‘-.–‘,
‘Z’: ‘–..’, ‘0’: ‘—–‘, ‘1’: ‘.—-‘, ‘2’: ‘..—‘, ‘3’: ‘…–‘,
‘4’: ‘….-‘, ‘5’: ‘…..’, ‘6’: ‘-….’, ‘7’: ‘–…’, ‘8’: ‘—..’,
‘9’: ‘—-.’, ‘.’: ‘.-.-.-‘, ‘,’: ‘–..–‘, ‘?’: ‘..–..’, “‘”: ‘.—-.’,
‘!’: ‘-.-.–‘, ‘/’: ‘-..-.’, ‘(‘: ‘-.–.’, ‘)’: ‘-.–.-‘, ‘&’: ‘.-…’,
‘:’: ‘—…’, ‘;’: ‘-.-.-.’, ‘=’: ‘-…-‘, ‘+’: ‘.-.-.’, ‘-‘: ‘-….-‘,
‘_’: ‘..–.-‘, ‘”‘: ‘.-..-.’, ‘$’: ‘…-..-‘, ‘@’: ‘.–.-.’, ‘ ‘: ‘/’
}

# Create a reverse dictionary for decoding
reverse_morse_dict = {v: k for k, v in morse_dict.items()}

def from_morse_code(morse_code):
message = ”
morse_code_list = morse_code.split(‘ ‘)
for code in morse_code_list:
if code == ‘/’:
message += ‘ ‘
elif code in reverse_morse_dict:
message += reverse_morse_dict[code]
else:
message += ”
return message

# Example usage:
morse_code_sequence = “.. / .- — / .- / … — ..-. – .– .- .-. . / -.. . …- . .-.. — .–.”
print(from_morse_code(morse_code_sequence))

The from_morse_code function works like this:

It splits the Morse code string by spaces to get individual Morse codes.
For each code, it finds the matching letter or symbol from the reverse dictionary.
It adds a space if it finds a slash (/).
It returns the decoded normal message.

Integrating with IoT Devices

Once the Morse code translator works well in Python, you can connect it with IoT devices. These devices can send and receive signals in real time. For example, sensors or buttons can send Morse code messages. The Python program can decode these signals and take action. This creates opportunities for innovative uses such as remote alerts, simple communication in harsh environments, or interactive IoT controls.

You can also send messages from the Python program to IoT devices. The program can convert text into Morse code and then transmit it as signals like light flashes or sound beeps. This way, IoT devices and Python code communicate easily using Morse code.

To do this, you can use communication tools like Bluetooth, Wi-Fi, or serial ports. This makes the system flexible for many IoT setups.

Hardware Setup for Real-Time Translation

To build a real-time Morse code translator with IoT, you need some basic hardware components. These include sensors like buttons or switches to input the Morse code signals. You may also use LEDs or buzzers to show the translated messages or provide feedback.

Connect these components to a microcontroller or a small computer like Raspberry Pi or Arduino. This device will run the Python program that encodes and decodes the Morse code. It will also handle communication with other IoT devices or networks.

Make sure the input device can detect short and long signals correctly. The program will interpret these signals as dots and dashes in Morse code. The output devices will then display or sound the translated message in real time.

Software Design for Real-Time Processing

The Python program should handle input signals in real time. It needs to detect the length of each signal to tell if it is a dot or a dash. The program also has to identify spaces between letters and words.

This requires measuring the time duration of button presses or sensor signals. Short presses mean dots. Longer presses mean dashes. Pauses between signals mark spaces.

The program collects these signals and converts them into Morse code. Then it decodes the Morse code into readable text. The decoded message can be sent to a display or stored for later use.

This approach helps the translator work smoothly with live signals from IoT devices.

Testing and Validation

After building the hardware and software, testing is important. You need to check if the translator reads the signals correctly. Test different messages with various lengths and characters.

Make sure the program handles dots and dashes accurately. Also, check if the spaces between letters and words are recognized properly.

Test the system with real IoT devices sending signals. Confirm that the Python program decodes the messages without errors.

If problems happen, adjust the timing or the code to improve accuracy. Repeat tests until the translator works well every time.

If your Morse code translator includes a web-based control panel or message viewer, testing its real-time performance across browsers and devices becomes important. Here, LambdaTest can help. It is an AI-powered test execution platform that supports both manual and automated testing across 3000+ browsers and operating systems. You can use it to test the frontend of your IoT interface for responsiveness, compatibility, and performance without needing physical test devices.

Conclusion

Building a real-time Morse code translator with Python can add useful communication to IoT projects. It helps devices send and receive messages using simple signals.

The project uses a clear mapping of characters to Morse code. It can convert messages to Morse code and back to text. By connecting with sensors and output devices, it works live with IoT hardware.

Testing the system ensures reliable performance. This translator can be a starting point for more complex IoT communication tools. It also supports basic remote signaling and low-bandwidth communication in constrained environments using lightweight protocols.
